• HP Tuners Fummins 08-10 6.4 5R110 Transmission Tuning (computer flashing)
1 4

HP Tuners Fummins 5R110 Trans Tuning Ford 08-10 6.4

HP Tuners Fummins 5R110 Trans Tuning Ford 08-10 6.4

599.99 CAD
599.99 CAD
Sale Sold out

00003


ECM/TCM tuning for the 08-10 6.4 Ford Super Duty trucks swapped to a Cummins engine.

2 Credits needed if you vehicle has not been tuned before, this service is intended for older MPVI 2/2+ where a customer cannot use TDN app. TDN tuning is found here if you need an MPVI and tuning use this link

With a need to properly tune the 5r110 in the market we have finally come out with a real solution, custom OS will full flash over top your current calibration. . You will be emailed a user guide once your order is placed, explaining the steps and so on.



The problem lies in the torque base ECM logic and the many limp modes in the factory tuning, these are in place to save the 6.4 motor in the event of problems. What happens with a swapped truck is many sensors and logic is just not there and the limp modes built-in removes the torque value resulting in a drastic line pressure drop in the transmission. When this happens the flare or missed gear happens, upgraded direct/EPC helps but is not a real fix.


Our testing and tuning was done with a tuned 03 Common rail (running a max effort tune) and a 350,000Km (215,000 Miles) stock and well used with a low stall converter, this trans was not serviced or inspected prior to installation. Sensors hooked up MAP, oil PSI/temp, coolant temp.

Benefits

  • No sensors are needed in the exhaust to start
  • No check engine light
  • No cleaning filter
  • No green wrench
  • No jumping pin 53, keeping neutral safety working
  • Trans diagnostics is still active
  • Revised "Hybrid" tuning and tow-haul
  • Adaptive learning
  • Optional turn-off battery/charging light for guys running another brand of alternator

What is the MPVI2+?

Connect > It is an OBDII interface tool that connects VCM Suite to your vehicle’s various control modules. Read > Diagnose and clear trouble codes, monitor vehicle performance or read from your various vehicle control modules. Edit > Optimize vehicle performance, fuel economy, and more. Write > License and tune any vehicle currently supported by HP Tuners. Drive >>>>>

Note: The MPVI2+ does not include any pre-loaded tunes or calibrations.


HARDWARE & SOFTWARE

Combine the MPVI2+ With VCM Suite for the most comprehensive scanning, logging and calibration tools on the market. Whether you are building a dedicated track car, a next level streetcar, or just want more fuel efficiency or better towing for your daily driver, HP Tuners has the tools to get the most out of your vehicle.

DOWNLOADVCM Suite

90 days of adjustments (starts when we start tuning. not order date)
